AES Flood Beam Work Lamp LED563FL

The AES LED563FL Flood Beam Work Lamp is a high-output, rectangular work light designed for versatility and durability in tough environments. Its slim profile and single-bolt fitting allow for easy installation on a wide range of vehicles, from utility and agricultural machinery to off-road and commercial fleets.

Fitted with nine powerful 1.5W LEDs, the lamp produces a bright 1980 lumens of light at a clear 6000K colour temperature. The wide flood beam pattern delivers excellent coverage, improving visibility and safety in dark or challenging conditions.

Built for reliability, the LED563FL is rated IP68 and IP69K, offering complete protection against dust, immersion, and high-pressure water. It meets ECE R10 standards for electromagnetic compatibility and is available with an optional Superseal connector for a secure, weather-resistant connection.

LED563FL Technical information

• LED power: 15W with wide flood beam
• Light output: 1980 lumens at 6000K colour temperature
• IP rating: IP68 and IP69K for extreme environmental protection
• Design: Durable rectangular shape with single-bolt mounting
• Certification: ECE R10 approved
• Optional Superseal connector
• Warranty: 2 years

Ideal for reverse lighting, work area illumination, and harsh weather applications.

Download LED563FL datasheet

For full specifications, dimensions, and wiring details, Download Data Sheet here.
