AMC 0.75mm² 24/0.20mm Thin wall Automotive Cable – Tracer Striped Bi-Colour, 100m

High-temperature, low-voltage automotive wiring cable designed for automotive, marine and related applications. This bi-colour automotive wire with tracer stripe provides clear tracer colours for easy circuit identification, making it ideal for complex wiring looms and harnesses. Manufactured by AMC, this cable delivers reliable performance, compact design and durability in demanding environments. It is also perfect as a 1 mm single core cable for precise connections in low voltage cable systems.

Key features of AMC thin wall automotive cable

• Manufactured to ISO 6722-1:2011 (Class B), rated to 105ºC
• Plain copper conductor to BS EN 60228:2005
• PVC insulation suitable for continuous operation from -40ºC to +105ºC, with short-term peaks up to 120ºC
• Suitable for 12V and 24V systems (maximum voltage: 60V)
• Reduced insulation thickness for significant weight and volume savings in large harnesses
• Excellent resistance to petrol, diesel, lubricating oils and diluted acids
• Durable insulation provides good protection against abrasion and cut-through

Specifications

• Conductor size: 0.75mm²
• Stranding: 24/0.20mm
• Conductor material: Plain copper
• Cable type: thin wall automotive cable, automotive wire with tracer stripe, bi-colour automotive trace cable, low voltage cable, 0.75 mm single core cable

Typical applications for automotive wire with tracer stripe

This automotive wire with tracer stripe is ideal for use in automotive and marine wiring systems where cable low voltage with striped tracer colours is required. Its compact, heat-resistant and durable design makes it a trusted choice for professional harnesses and installations, and a preferred option among leading automotive cable suppliers.

Why is AMC cable a better choice for your wiring needs?

AMC is a leading UK auto cable manufacturer, producing premium automotive wiring cable trusted for quality, durability and performance. Made to ISO 6722 standards with high-purity copper, AMC cables deliver excellent conductivity, durability and low resistance. Unlike cheaper alternatives, cable AMC offers consistent insulation quality, strong resistance to heat, fuels, oils and abrasion, making it a reliable choice for automotive, marine and leisure applications where long-term performance and safety are essential.

Extruded tracer for long-term reliability

AMC bi-coloured Thinwall cable features an extruded tracer colour permanently embedded into the insulation for long-term durability, reliable circuit identification, and compliance with automotive specifications. Unlike painted tracers that can wear away over time and complicate maintenance and fault finding, the extruded tracer remains clearly visible throughout the life of the cable. Read more about the difference between extruded and painted tracers.
